Sena SMH10-11 Motorcycle Bluetooth Headset / Intercom User Manual

Package Contents

• Sena SMH10-11 Bluetooth Headset
• Universal Microphone Kit
• USB Charging Cable
• Mounting Accessories
• User Manual

Installation

1. Choose a suitable location on your helmet to attach the clamp mount.
2. Slide the clamp mount between the helmet shell and the inner padding.
3. Tighten the screws on the clamp mount to secure it to the helmet.
4. Attach the main unit to the clamp mount by sliding it down until it clicks into place.
5. Adjust the position of the microphone and speakers to ensure optimal sound quality and comfort.
6. Use the provided Velcro pads to attach the speakers inside your helmet's ear pockets.

Charging the Headset

1. Connect the provided USB charging cable to the headset's charging port.
2. Connect the other end of the cable to a USB power source (computer, wall adapter, etc.).
3. Charge the headset until the LED indicator turns blue, indicating a full charge (approximately 2.5 hours).

Pairing the Headset with Your Device

1. Ensure your device's Bluetooth is turned on.
2. Press and hold the Phone Button on the headset for 5 seconds until the LED flashes red and blue.
3. Search for available Bluetooth devices on your phone or other device and select "Sena SMH10" from the list.
4. Enter the passcode "0000" if prompted.
5. Once connected, the LED will flash blue every 2 seconds.

Basic Operations

1. Turn on the headset: Press and hold the Jog Dial and Phone Button for 1 second.
2. Turn off the headset: Press and hold the Jog Dial and Phone Button for 5 seconds.
3. Answer a call: Tap the Phone Button once.
4. End a call: Tap the Phone Button once.
5. Reject a call: Press and hold the Phone Button for 2 seconds.
6. Adjust volume: Rotate the Jog Dial clockwise or counterclockwise.
7. Play or pause music: Press and hold the Jog Dial for 1 second.
8. Next track: Rotate and hold the Jog Dial clockwise for 1 second.
9. Previous track: Rotate and hold the Jog Dial counterclockwise for 1 second.

Troubleshooting Tips

• If you experience difficulty connecting to your device, try turning off Bluetooth and turning it back on.
• Ensure the headset is fully charged before use.
• Make sure the headset and your device are within 10 meters (33 feet) of each other.
• Reset the headset by pressing and holding the Jog Dial and Phone Button for 12 seconds.

Frequently Asked Questions

How do I connect the headset to multiple devices?

To connect the Sena SMH10-11 to multiple devices, follow the pairing steps for each device. The headset can remember up to four paired devices.

How do I use the intercom feature with other riders?

To use the intercom feature, first pair the headsets by pressing and holding the Jog Dial for 5 seconds on both devices. Once paired, tap the Jog Dial on one headset to initiate the intercom conversation.

How long does the battery last on a single charge?

The Sena SMH10-11 offers up to 12 hours of talk time and 10 days of standby time on a single charge.

Is the headset waterproof?

The Sena SMH10-11 is not fully waterproof, but it is designed to withstand bad weather and rain.

Can I use the headset with earplugs?

Yes, the headset's speakers are loud enough to be used with earplugs. Adjust the volume accordingly for a comfortable listening experience.

Product: Sena SMH10-11 Motorcycle Bluetooth Headset / Intercom with Universal Microphone Kit (Single) , Black - Automotive Parts & Accessories

Q: What is the range of the intercom feature?
A: The intercom feature has a range of up to 900 meters (980 yards).

Q: What are the connectivity options of this headset?
A: This headset features Bluetooth 3.0 connectivity, which allows you to listen to and share music, make phone calls with speed dialing, and participate in a four-way intercom conversation.

Q: Does this headset have noise-canceling technology?
A: Yes, this headset features Advanced Noise Control technology that cuts down on background noise for both incoming and outgoing audio.

Q: What is included in the package?
A: The package includes a Universal Microphone Kit.

Q: How long does the battery last on a single charge?
A: The battery lasts up to 12 hours of talk time and 10 days of stand-by time on a single charge.

Q: Is the firmware upgradable?
A: Yes, the firmware is upgradable. Make sure you install the firmware manager onto your computer.

Q: Can I transfer this headset to a different helmet if I get a new one?
A: Yes, you can transfer the entire unit to a new helmet. You can also purchase different mounting kits to leave them on different helmets and then simply clip the main unit on and off to the different helmets as needed.

Q: Will this headset work with Harley Davidson Touring bike audio/CB 7-pin systems?
A: This unit gives your helmet wireless (Bluetooth) capabilities. It doesn't really give you a way to plug into your existing (non-Bluetooth system). To get that capability, you would have to add the SM10-01, which would allow you to turn your bike's current system into a Bluetooth connectable source.

Q: What are the pros and cons of this headset?
A: Pros include the ability to make phone calls from the road, loud speakers, good battery life, and durability in bad weather. Cons include average sound quality, occasional Bluetooth connectivity issues, awkward speaker placement on some helmets, and cumbersome USB charging.

Overall, the Sena SMH10-11 Motorcycle Bluetooth Headset / Intercom with Universal Microphone Kit is a good option for motorcyclists looking for a reliable and feature-packed headset at an affordable price point. However, those who prioritize sound quality may want to consider other options.
