Samsung UBD-K8500 3D Wi-Fi 4K Ultra HD Blu-ray Player User Manual

Table of Contents

1. Getting Started
2. Connecting the Blu-ray Player
3. Setting Up the Blu-ray Player
4. Using the Blu-ray Player
5. Troubleshooting Tips
6. Frequently Asked Questions

1. Getting Started

Before setting up your Samsung UBD-K8500 3D Wi-Fi 4K Ultra HD Blu-ray Player, please ensure that you have the following items included in the box:

• Blu-ray Player
• Remote Controller
• Battery

2. Connecting the Blu-ray Player

1. Place the Blu-ray player on a flat surface near your Samsung Curved SUHD TV or other compatible television.
2. Connect the power cable to the back of the Blu-ray player and plug it into a power outlet.
3. Connect an HDMI cable (not included) to the HDMI OUT port on the back of the Blu-ray player and the other end to an HDMI IN port on your TV. If your A/V receiver is not HDCP 2.2 compatible, use the second HDMI OUT port on the Blu-ray player to connect an HDMI cable to the A/V receiver for audio output.
4. Optional: Connect an Ethernet cable (not included) to the Ethernet port on the back of the Blu-ray player and the other end to your router for a wired internet connection. Alternatively, you can use the built-in Wi-Fi for a wireless connection.

3. Setting Up the Blu-ray Player

1. Turn on your TV and select the appropriate HDMI input.
2. Turn on the Blu-ray player using the power button on the front of the device or the remote controller.
3. Follow the on-screen instructions to complete the initial setup, including language selection, network settings, and time zone.
4. Sign in or create a Samsung account to access additional features and services.

4. Using the Blu-ray Player

1. Insert a 4K Ultra HD Blu-ray, 3D Blu-ray, Blu-ray, DVD, or CD into the disc tray and close it.
2. Use the remote controller to navigate the Blu-ray player's menu and control playback.
3. Access streaming services and apps by selecting the desired app from the main menu.
4. Adjust picture and sound settings by selecting the Settings option from the main menu.
5. For screen mirroring with Android devices, select the Screen Mirroring option from the main menu.

5. Troubleshooting Tips

1. If the Blu-ray player is not turning on, ensure the power cable is securely connected and the power outlet is functional.
2. If there is no picture or sound, check the HDMI cable connections and ensure the TV is set to the correct input.
3. If the remote controller is not working, check the battery and replace it if necessary.
4. If you experience issues with streaming services or apps, check your internet connection and restart the Blu-ray player.
5. If the Blu-ray player is not playing discs properly, ensure the disc is clean and compatible with the player.

6. Frequently Asked Questions

Is the Samsung UBD-K8500 compatible with non-Samsung TVs?

Yes, the UBD-K8500 is compatible with any television that has an HDMI input and supports HDCP 2.2 for 4K Ultra HD playback.

Can I play my old DVDs and CDs on the UBD-K8500?

Yes, the UBD-K8500 is a universal disc player and can play DVDs, CDs, and Blu-ray discs in addition to 4K Ultra HD Blu-ray discs.

How do I connect the UBD-K8500 to the internet?

You can connect the UBD-K8500 to the internet using either a wired Ethernet connection or the built-in Wi-Fi feature.

What streaming services are available on the UBD-K8500?

The UBD-K8500 comes preloaded with popular streaming services such as Netflix and Amazon. You can access these services directly from the main menu.

Do I need a 4K TV to use the UBD-K8500?

While a 4K TV is recommended for the best picture quality, you can still use the UBD-K8500 with a lower-resolution TV. The player will automatically upscale lower-resolution content to the highest resolution supported by your TV.

Q: What is the Samsung UBD-K8500 Ultra HD Blu-ray Player?
A: The Samsung UBD-K8500 Ultra HD Blu-ray Player is a device designed to deliver the ultimate cinematic experience. It allows you to play 4K Ultra HD movies at 4X the resolution of 1080p, providing a level of detail and clarity like never before.

Q: What are the features of this player?
A: Some of the key features of this player include:
- Play 4K Ultra HD movies at 4X the resolution of 1080p
- High Dynamic Range (HDR) for greater color contrast and brightness
- Reveals up to 2x the color range and 64x the color expressions of a conventional Blu-Ray player
- Dolby True HD and DTS HD Master Audio for ultimate digital sound quality
- Built-in Wi-Fi for syncing and streaming content from your PC and mobile device
- Compatibility with all old music CDs, DVDs, and Blu-ray discs

Q: Does this player support 3D Blu-ray discs?
A: Yes, it does support 3D Blu-ray discs. However, it is important to note that most 4K TVs do not support 3D.

Q: Is this player capable of playing new 4K UHD movies?
A: Yes, it is capable of playing new 4K UHD movies that are slowly popping up on the market.

Q: Is this player region-free?
A: There is no information provided by the manufacturer regarding whether or not this player is region-free.

Q: Does this player work for passive and active 3D TVs?
A: Yes, it works for both passive and active 3D TVs. However, it is important to note that most 4K TVs do not support 3D.

Q: Will this player upscale regular Blu-rays to near 4K quality?
A: Yes, this player will upscale regular Blu-rays to near 4K quality.

Q: What are the dimensions and weight of this player?
A: The dimensions of this player are 15.98 x 9.06 x 1.76 inches and it weighs 4.19 pounds.

Q: What is included in the box?
A: The box includes the Blu-ray player, remote controller, and battery.

Q: Is this player compatible with Dolby Atmos?
A: As long as you have a receiver that will decode the ATMOS signal, then it will work. However, the player will not decode the signal, it will only send it to the receiver to be decoded.

Q: Does this player support the new H.265 HEVC standard?
A: Yes, this player supports the H.265 HEVC standard.

Q: Why is this player more expensive than other 4K players?
A: This player is more expensive because it can play 4K discs, which is currently only available on a limited number of players. Other 4K players are upscale ones that cannot play 4K discs, only Blu-rays.
