DIGITNOW Record Player User Manual

Table of Contents

1. Getting Started
2. Playing Vinyl Records
3. Using Bluetooth Function
4. Listening to FM Radio
5. Recording to USB/SD Card
6. Troubleshooting Tips
7. Frequently Asked Questions

1. Getting Started

1. Unpack the DIGITNOW Record Player from its packaging.
2. Ensure that all components, including the power adapter, are present.
3. Place the record player on a flat, stable surface.
4. Connect the power adapter to the DC input on the back of the record player and plug it into a wall outlet.
5. Turn on the record player using the power switch located on the front of the unit.

2. Playing Vinyl Records

1. Open the record player's lid to reveal the turntable.
2. Select the desired speed (33, 45, or 78 RPM) using the speed selector switch on the front of the unit.
3. Place the vinyl record on the turntable, ensuring that it is properly centered.
4. Remove the protective cover from the stylus and lift the tonearm using the tonearm lift lever.
5. Position the tonearm over the beginning of the record and gently lower it onto the vinyl using the tonearm lift lever.
6. The record will begin to play through the built-in speakers. Adjust the volume using the volume control knob on the front of the unit.
7. To stop playback, lift the tonearm using the tonearm lift lever and return it to its resting position. Turn off the power switch when finished.

3. Using Bluetooth Function

1. Turn on the record player using the power switch located on the front of the unit.
2. Press the "Mode" button until "BT" appears on the LCD screen.
3. Enable Bluetooth on your external device (e.g., smartphone, tablet) and search for available devices.
4. Select "DIGITNOW" from the list of available devices and connect.
5. Once connected, play music from your external device, and it will be streamed through the record player's built-in speakers.

4. Listening to FM Radio

1. Turn on the record player using the power switch located on the front of the unit.
2. Press the "Mode" button until "FM" appears on the LCD screen.
3. Use the "Tuning+" and "Tuning-" buttons to search for radio stations. The LCD screen will display the frequency of the selected station.
4. Adjust the volume using the volume control knob on the front of the unit.

5. Recording to USB/SD Card

1. Insert a USB flash drive or SD card (not included) into the appropriate slot on the front of the record player.
2. Play a vinyl record or tune to a radio station as described in previous sections.
3. Press the "Rec" button to start recording. The LCD screen will display "REC" and the elapsed recording time.
4. Press the "Rec" button again to stop recording. The recorded audio will be saved as an MP3 file on the USB flash drive or SD card.
5. Remove the USB flash drive or SD card and transfer the recorded audio files to a computer or other device for playback and storage.

6. Troubleshooting Tips

1. If the record player does not turn on, ensure that the power adapter is properly connected and the outlet is functioning.
2. If the sound quality is poor or distorted, check the stylus for damage and replace if necessary.
3. If the Bluetooth connection is not working, ensure that your external device is within range and properly connected to the record player.
4. If the FM radio reception is weak, adjust the position of the record player and/or the attached antenna for better reception.
5. If the recording function is not working, ensure that the USB flash drive or SD card is properly inserted and has sufficient storage space.

7. Frequently Asked Questions

Can I connect external speakers to the record player?

Yes, you can connect external speakers using the RCA output on the back of the unit.

Does the record player have a built-in CD player or cassette player?

No, this model does not include a CD player or cassette player. However, other DIGITNOW models do have these features.

Can I play 7", 10", and 12" records on this record player?

Yes, this record player supports all three sizes of records.

Is the turntable made of plastic or metal?

The turntable is made of plastic, but it is recommended to use a silicone mat for better performance and protection of your vinyl records.

Can I listen to music privately using headphones?

Yes, there is a headphone jack on the front of the unit for private listening.

Q: What are the features of the DIGITNOW Record Player?
A: The DIGITNOW Record Player is a unique multi-function leather suitcase turntable that includes a record player, FM radio, Bluetooth audio receiver, LP to MP3 recording, and MP3 player function all in one. It has both USB recording capabilities and can convert vinyl records and radio programs to MP3 from your USB flash/SD card. It also has 3-speeds (33,45 and 78 RPM) and built-in stereo speakers for great sound. Additionally, it has a headphone jack for private listening and RCA line out to acoustics. It also has an AUX in and Bluetooth for connecting other devices such as CD players, iPods, iPhones, etc.

Q: Is the DIGITNOW Record Player portable?
A: Yes, the DIGITNOW Record Player is portable and made from lightweight material. It is easy to carry from one place to another and does not take up too much space in the car.

Q: What is the compatibility of the DIGITNOW Record Player?
A: The DIGITNOW Record Player is Bluetooth, SD card, and USB-compatible so you can play music on other devices with a record player for that retro feeling.

Q: Does the DIGITNOW Record Player have good sound quality?
A: Yes, the DIGITNOW Record Player has good sound quality. The headphone jack on the record player allows you to listen to music at any time and anywhere, and it supports Bluetooth.

Q: Where can the DIGITNOW Record Player be used?
A: The DIGITNOW Record Player can be used anywhere. It is a good decoration for your living room, bedroom, study room, etc.

Q: What are the specifications of the DIGITNOW Record Player?
A: The DIGITNOW Record Player has dimensions of 13.8 x 10 x 4.5 inches and weighs 5.5 pounds. It is wireless and wired, made of vinyl material, and has an AC motor power source. It is available in orange color and has a 12-month warranty.

Q: Can the DIGITNOW Record Player record vinyl to a USB drive?
A: Yes, the DIGITNOW Record Player can record vinyl to a USB drive. The player must be turned on, and it is necessary to insert the USB drive into the appropriate slot first. Once you have a record in place, with stylus ready to start playing push that button firmly. The screen will display a red 'rec' image. You are ready to record.

Q: Does the DIGITNOW Record Player come with a power adapter?
A: Yes, the DIGITNOW Record Player comes with a two-pronged plug suitable for any (U.S.A., 120v) standard wall socket.

Q: Can you play music from an SD card on the DIGITNOW Record Player?
A: Yes, you can play music from an SD card on the DIGITNOW Record Player.

Q: Is the DIGITNOW Record Player belt drive or direct drive?
A: The DIGITNOW Record Player is belt drive.

Q: Can the DIGITNOW Record Player be synced up to a Bluetooth speaker?
A: Yes, it can be synced up to a Bluetooth speaker or other wireless devices.
