WiFi LED Deck Lights Kit RGBW User Manual

Package Contents

• 20 x LED Deck Lights
• 1 x 30W LED Power Supply
• 1 x LED WiFi Controller

Installation

1. Choose the location where you want to install the LED deck lights.
2. Drill holes with a diameter of 1.38" (35mm) at the desired locations.
3. Insert the LED deck lights into the holes and secure them in place.
4. Connect the LED deck lights to the LED WiFi controller using the male and female waterproof connectors. The distance between each light is 3.28ft (1m).
5. Connect the LED WiFi controller to the 30W LED power supply.
6. Plug the power supply into an AC110-265V power source.

WiFi Connection and App Setup

1. Download the app compatible with your LED WiFi controller (refer to the manufacturer's instructions for the specific app).
2. Connect your smartphone to your home WiFi network.
3. Open the app and follow the instructions to connect the LED WiFi controller to your home WiFi network.
4. Once connected, you can control the LED deck lights using the app, including color changing, dimming, and setting schedules.

Remote Control

Use the included remote control to turn the lights on/off, change colors, adjust brightness, and switch between different modes.

Voice Control with Amazon Alexa or Google Assistant

1. Ensure your LED WiFi controller is connected to your home WiFi network.
2. Set up your Amazon Alexa or Google Assistant device according to the manufacturer's instructions.
3. Enable the skill or action for the LED WiFi controller in the Alexa or Google Assistant app.
4. Link your LED WiFi controller account to your Alexa or Google Assistant account.
5. Assign a name to each set of lights and use the name to control the lights with voice commands.

Troubleshooting Tips

1. If the lights are not turning on, check the connections between the lights, the WiFi controller, and the power supply. Ensure all connections are secure and the power supply is plugged in.
2. If the WiFi connection is not working, reset the LED WiFi controller and try connecting again. Ensure your smartphone is connected to your home WiFi network during the setup process.
3. If the lights are flickering or malfunctioning, contact the manufacturer for assistance or a replacement part.
4. If the remote control is not working, ensure the batteries are properly installed and not depleted.

Frequently Asked Questions

Can I extend the distance between the lights?

Yes, you can purchase additional 5-pin extension cables separately to extend the distance between the lights.

Are the lights dimmable?

Yes, the lights are dimmable using the app, remote control, or voice commands with Amazon Alexa or Google Assistant.

Can I control multiple sets of lights with one app or remote control?

Yes, you can create a group for all your smart devices and control them all with one command using the app. You can also control multiple sets of lights with the included remote control.

Can I use these lights indoors and outdoors?

Yes, the lights and cables are IP67 waterproof and safe for both indoor and outdoor use.

Do the lights work with a smart plug or switch?

Yes, you can use a smart plug or switch to control the power supply for the lights. This will allow you to turn the lights on and off using the smart plug or switch, but you will still need to use the app, remote control, or voice commands to change colors and adjust brightness.

Q: What is the model number of the FVTLED WiFi LED Deck Lights Kit RGBW?
A: The model number of the FVTLED WiFi LED Deck Lights Kit RGBW is D45B.

Q: Can I control these lights with my smartphone?
A: Yes, you can control these lights with your smartphone using the WiFi controller that comes with the kit.

Q: Is this product compatible with Alexa and Google Home?
A: Yes, this product is compatible with Alexa and Google Home, allowing you to control the lights with your voice.

Q: Are these lights waterproof?
A: Yes, these lights are IP67 waterproof and safe for indoor and outdoor use.

Q: How many lights can be connected to the power supply that comes with the set?
A: The transformer supplies 30W so 30 of the 1W lights can be connected to it.

Q: Are these lights dimmable?
A: Yes, these LED lights are dimmable and can be controlled using the included remote or smartphone app.

Q: What are the dimensions of each light?
A: Each light has a diameter of 1.77 inches and a height of 1.02 inches.

Q: Can I set these lights to stay on a specific color, such as white only?
A: Yes, you can set these lights to stay on a specific color, including white.

Q: How long are the connectors that come with these lights?
A: The connectors that come with these lights are double 1.6ft wires and the length between each light is 3.2ft. If you need to make them different lengths, you can purchase extension cables separately.

Q: Can these lights be installed on a horizontal surface that is exposed to rain?
A: Yes, these lights can be installed on a horizontal surface that is exposed to rain as they are IP67 waterproof.
