KECAG Mini Portable WiFi Projector User Manual

Table of Contents

1. Package Contents
2. Setting Up the Projector
3. Connecting Input Sources
4. Adjusting the Projection
5. Troubleshooting Tips
6. Frequently Asked Questions

1. Package Contents

• 1 x Projector
• 1 x Projector Screen
• 1 x Remote Control
• 1 x HDMI Cable
• 1 x Power Cable
• 1 x User Manual

2. Setting Up the Projector

1. Place the projector on a stable, flat surface or mount it on a tripod or ceiling-mount (not included).
2. Connect the power cable to the projector and plug it into an electrical outlet.
3. Turn on the projector using the power button on the projector or the remote control.
4. Unroll the projector screen and set it up in front of the projector.

3. Connecting Input Sources

The projector supports multiple input sources, including WiFi, HDMI, USB, TF Card, VGA, and AV.

1. WiFi Connection: Connect your smartphone to the projector using WiFi. Note: This projector does not support 5G internet.
2. HDMI Connection: Connect devices such as laptops, PCs, TV boxes, gaming consoles, and streaming devices using the included HDMI cable.
3. USB/TF Card Connection: Connect USB flash drives, SD cards, or other media players using the USB or TF card slots.
4. VGA Connection: Connect PCs or laptops using a VGA cable (not included).
5. AV Connection: Connect DVD players or older gaming consoles using an AV cable (not included).

4. Adjusting the Projection

1. Adjust the projection distance between 1 and 5 meters to achieve a projection size of 32 to 200 inches.
2. Use the focus ring on the projector to fine-tune the image sharpness.
3. Adjust the keystone correction slider to correct any image distortion.
4. Change the projection ratio between 4:3 and 16:9 as needed.

5. Troubleshooting Tips

• Projector not turning on: Ensure the power cable is securely connected and plugged into a working electrical outlet.
• No image or poor image quality: Check the input source connections and adjust the focus ring and keystone correction.
• Weak or no audio: Check the built-in speaker volume and consider connecting external speakers for better audio quality.
• WiFi connection issues: Ensure your smartphone is connected to a 2.4G WiFi network and try reconnecting.

6. Frequently Asked Questions

Q: Can I connect the projector to a Bluetooth speaker?

A: No, this projector does not support Bluetooth connectivity. However, you can connect external speakers using an audio cable.

Q: Is this projector suitable for business presentations?

A: This projector is not recommended for PPT, Word, Excel, or business presentations. It is best suited for home entertainment and movie watching.

Q: Can I use this projector outdoors?

A: Yes, this projector can be used outdoors, but it is recommended to use it in a dark environment for better performance.

Q: Does this projector support 5G internet?

A: No, this projector only supports 2.4G WiFi connections.

Q: What is the native resolution of the KECAG Mini Portable WiFi Projector?
A: The native resolution of this projector is 1080x720 pixels, and it supports 1080P.

Q: What is the contrast ratio of this projector?
A: The contrast ratio of this projector is 3000:1.

Q: What are the connectivity options for this projector?
A: This projector has multiple connectivity options, including WiFi, HDMI, USB, TF, VGA, and AV interfaces.

Q: Can this projector be used for business presentations?
A: No, it is not recommended to use this projector for PPT, Word, Excel or business presentations.

Q: Does this projector come with a screen?
A: Yes, this projector comes with a 100" projector screen.

Q: Can this projector be mounted on a ceiling or tripod stand?
A: Yes, it can be mounted on a ceiling or tripod stand. The bottom of the projector is equipped with a lifting function that allows for vertical height adjustment.

Q: What is the projection distance and size range for this projector?
A: The projection distance for this projector is 1-5 meters, and the projection size range is 32-200 inches.

Q: Does this projector support rear projection or have the ability to flip the video left to right?
A: No, it does not support rear projection or have the ability to flip the video left to right.

Q: Is this projector compatible with Android phones?
A: Yes, it is compatible with Android phones.

Q: What is the weight and dimensions of this projector?
A: The weight of this projector is 2.99 pounds, and its dimensions are 8.6 x 6.1 x 2.8 inches.
