User Manual for 2K Security Cameras Outdoor - 3MP Color Night Vision Wireless WiFi Home Video Surveillance

Table of Contents

1. Package Contents
2. Installation
3. Connecting the Camera to Wi-Fi
4. Using the Smartphone App
5. Camera Functions and Features
6. Troubleshooting
7. Frequently Asked Questions

1. Package Contents

• 2K Security Camera
• Power Adapter
• Mounting Bracket
• Screws and Wall Anchors
• User Manual

2. Installation

1. Choose a suitable location for the camera, ensuring it has a clear view of the area you want to monitor.
2. Use the included mounting bracket to mark the screw holes on the wall or ceiling.
3. Drill holes and insert wall anchors if needed.
4. Secure the mounting bracket to the wall or ceiling with the provided screws.
5. Attach the camera to the mounting bracket and adjust the angle as needed.
6. Plug in the power adapter and connect it to the camera.

3. Connecting the Camera to Wi-Fi

1. Download the smartphone app by scanning the QR code provided in the user manual or searching for it in your device's app store.
2. Open the app and create an account or sign in if you already have one.
3. Follow the in-app instructions to connect the camera to your 2.4G Wi-Fi network.
4. Ensure the camera is connected and functioning properly within the app.

4. Using the Smartphone App

1. Open the app and sign in to your account.
2. Select the camera from the list of connected devices.
3. Use the app to control the camera's pan, tilt, and zoom functions.
4. Enable or disable features such as motion detection, auto tracking, and night vision as needed.
5. Adjust the camera's settings, including detection area, sensitivity, and alerts.
6. View live footage and recorded videos from the camera.
7. Share access to the camera with family members or friends by creating guest accounts.

5. Camera Functions and Features

• 2K Super Clear Image
• Smart Motion Detection
• Encryption Protocol for secure recording and multi-user access
• Pan, Tilt, and Zoom functionality
• IP66 Waterproof rating
• 2-Way Audio
• 3 Night Vision Modes

6. Troubleshooting

1. Camera not connecting to Wi-Fi: Ensure your Wi-Fi network is 2.4G and that the camera is within range of your router. Reset the camera and try connecting again.
2. Camera not responding in the app: Check if the camera is connected to Wi-Fi and powered on. Restart the app and try again.
3. Poor video quality: Adjust the camera's angle and ensure it is clean and free of obstructions. Check your Wi-Fi connection and ensure the camera is within range of your router.
4. Issues with motion detection or alerts: Adjust the detection area and sensitivity settings within the app. Ensure your camera's firmware is up to date.
5. Camera not recording to the micro SD card: Check if the SD card is properly inserted and formatted. Ensure the card is not full or damaged.

7. Frequently Asked Questions

1. Can the camera be used with 5G Wi-Fi networks?
   No, this camera only works with 2.4G Wi-Fi networks.
2. What is the maximum SD card capacity supported?
   The camera supports micro SD cards up to 128GB.
3. Can I connect the camera to a computer or use a web browser to view the footage?
   No, the camera can only be accessed and controlled through the smartphone app.
4. Is the camera compatible with other apps?
   No, the camera is designed to work exclusively with its dedicated app.
5. Can the camera be used indoors?
   Yes, the camera can be used both indoors and outdoors.

Product FAQ:

Q: What is the video resolution of this outdoor camera?
A: This outdoor camera has a stunning 3-Megapixel 2304*1296p video resolution with enhanced low light capability utilizing a CMOS progressive image sensor and chipset.

Q: Does this camera work with both WiFi and wired power?
A: No, this WiFi camera ONLY works with 2.4G WiFi and Wired Power.

Q: How does the motion detection feature work on this camera?
A: This outdoor security camera adopted motion sensors to detect motion and sends alerts to your phone, reducing false alarms caused by rain, insects, fallen leaves, etc. Customize Detection area and sensitivity (low/medium/high） can also be customized on APP to focus on the zone you want. Meanwhile, the home security cameras will automatically track and record every movement of the intruder and "alarm" when needed.

Q: Is it safe to record surveillance footage on this camera?
A: Yes, under the Encryption Protocol, you’re the only one who has access to the surveillance camera. You could store 24/7 surveillance footage in the micro sd card(not included). This home security camera allows you create several guest accounts and share the videos instantly with your family and friends.

Q: Is this camera weatherproof?
A: Yes, this outdoor security camera system is IP66 waterproof which allows it to withstand extreme weather such as rain, snow, and heat.

Q: How many night vision modes does this camera have?
A: This outdoor security cameras have three night vision modes - infrared night vision, floodlights mode, and full-color mode day and night.

Q: Can I use a 500gb SD card for recording?
A: No, it is not compatible with a 500gb SD card.

Q: How many cameras come with this product?
A: One camera comes with this product, and you’ll need to buy an SD memory card to record. You may need a WiFi extender if your signal isn’t strong enough. You need a 2.4Ghz WiFi, and when you set up your camera with your smartphone, you’ll need to be on the same network. You can have 4 cameras on this system.

Q: Is the app used to run the camera worth using?
A: The camera is good, but the app used to run the camera is not very good.

Q: What is the operating temperature range of this camera?
A: The camera can operate in temperatures regularly below -4 deg F.

Q: Does the SD card rewrite itself when full?
A: Yes, it does.

Q: How do you set up motion detection on this camera?
A: You can find the mobile tracking function in the mobile app settings and keep it on.
