FANGOR S20 Mini Sound Bar User Manual

Table of Contents

1. Package Contents
2. Getting Started
3. Connecting the Sound Bar to Your Devices
4. Using the Remote Control
5. Adjusting Sound Settings
6. Troubleshooting Tips
7. Frequently Asked Questions

1. Package Contents

• FANGOR S20 Mini Sound Bar
• Remote Control
• Optical Cable
• Wall Mounting Accessories
• User Manual

2. Getting Started

Place the sound bar on a flat surface or mount it on the wall using the included wall mounting accessories. Ensure the sound bar is in a central position relative to your TV or projector for optimal sound quality.

3. Connecting the Sound Bar to Your Devices

The FANGOR S20 Mini Sound Bar offers multiple connection options, including Bluetooth, USB, HDMI ARC, optical, and AUX. Choose the appropriate connection method for your device:

Bluetooth Connection

1. Power on your sound bar and enable Bluetooth mode by pressing the "Bluetooth" button on the remote control.
2. On your Bluetooth-enabled device, go to the Bluetooth settings and search for available devices.
3. Select "FANGOR S20" from the list of devices to pair and connect.

USB Connection

Connect your USB device to the USB port on the back of the sound bar.

HDMI ARC Connection

Connect the HDMI ARC port on the sound bar to the HDMI ARC port on your TV or projector using an HDMI cable (not included).

Optical Connection

1. Connect the included optical cable to the optical port on the back of the sound bar.
2. Connect the other end of the optical cable to the optical port on your TV or projector.

AUX Connection

Connect your device to the AUX port on the back of the sound bar using a 3.5mm audio cable (not included).

4. Using the Remote Control

The remote control allows you to switch between different input modes, adjust volume, and change sound settings. Familiarize yourself with the remote control buttons:

• Power: Turn the sound bar on or off.
• Mute: Mute or unmute the sound.
• Volume +/-: Adjust the volume level.
• Bluetooth: Switch to Bluetooth mode.
• USB/AUX/OPT/HDMI: Switch between different input modes.
• Movie/Music/Dialog: Switch between different EQ modes.
• Bass +/-: Adjust the bass level.
• Treble +/-: Adjust the treble level.

5. Adjusting Sound Settings

Use the remote control to switch between different EQ modes (Movie, Music, Dialog) and adjust bass and treble levels to optimize the sound for your specific audio content.

6. Troubleshooting Tips

• If the sound bar is not producing sound, check that it is powered on and connected to your device correctly.
• If the sound quality is poor, try adjusting the EQ settings and bass/treble levels using the remote control.
• If the Bluetooth connection is unstable or not working, ensure your device is within the 30-foot transmission range and that there are no obstacles or interference sources nearby.
• If you experience issues with the remote control, try replacing the batteries and ensure there are no obstructions between the remote and the sound bar.

7. Frequently Asked Questions

Q: Can I connect multiple devices to the sound bar at once?

A: Yes, you can connect multiple devices using different connection methods (e.g., Bluetooth, USB, HDMI ARC, optical, AUX). However, only one input can be active at a time. Use the remote control to switch between input modes.

Q: What is the transmission range for Bluetooth connection?

A: The Bluetooth 5.0 technology allows for a transmission range of up to 30 feet in open areas.

Q: Can I use the sound bar with a projector?

A: Yes, you can connect the sound bar to a projector using the appropriate connection method (e.g., HDMI ARC, optical, AUX).

Q: Does the sound bar come with an HDMI cable?

A: No, the sound bar does not include an HDMI cable. You will need to purchase an HDMI cable separately if you wish to use the HDMI ARC connection.

Q: Can I mount the sound bar on the wall?

A: Yes, the sound bar comes with wall mounting accessories, allowing you to mount it on the wall if desired.

Q: What is the output power of the FANGOR S20 mini soundbar for TV?
A: The FANGOR S20 mini soundbar for TV is equipped with 60W output power.

Q: What are the built-in DSP and 3 EQ modes of the FANGOR S20 mini soundbar for TV?
A: The FANGOR S20 mini soundbar for TV has built-in DSP technology and provides 3 different equalizer modes (Movie, Music, Dialog) for amazing clarity and precision according to the audio you choose from.

Q: Can I connect my phone to the FANGOR soundbar via Bluetooth?
A: Yes, you can easily pair the FANGOR soundbar for TV to your phone via Bluetooth 5.0 wireless transmission technology to enjoy high fidelity sound.

Q: What are the available wired connections of the FANGOR S20 mini soundbar for TV?
A: The FANGOR S20 mini soundbar for TV has multiple wired connections including USB input, Optical input (optical cable included), AUX port, and HDMI ARC input.

Q: Is the FANGOR S20 mini soundbar for TV portable?
A: Yes, this 16 inch small soundbar for TV has a slim shape and is convenient to carry out.

Q: Does the FANGOR S20 mini soundbar for TV come with a warranty?
A: Yes, FANGOR offers 30 days unconditional refund service and 3 years professional technical support. If you have any problem, please contact them.
