User Manual for Geoyeao BT103 Sound Bar

Table of Contents

1. Package Contents
2. Setting Up Your Sound Bar
3. Connecting to Devices
4. Remote Control Functions
5. Adjusting Sound Settings
6. Troubleshooting Tips
7. Frequently Asked Questions

1. Package Contents

• Two tower speakers
• Remote controller
• Desktop gasket
• DC Adapter
• Long line cable
• Short line cable
• HDMI ARC Cable
• Coaxial digital audio cable
• AUX audio cable
• AUX to RCA audio cable
• Optical cable
• Wall mount screws
• User Manual

2. Setting Up Your Sound Bar

The Geoyeao BT103 Sound Bar can be used in three different configurations: as a horizontal sound bar, as dual tower speakers on the left and right sides of the TV, or mounted on the wall.

1. For horizontal sound bar configuration, use the short line cable to connect the two tower speakers together.
2. For dual tower speaker configuration, use the long line cable to connect the two tower speakers.
3. For wall mounting, use the included wall mount screws and follow the instructions in the user manual.

3. Connecting to Devices

The Geoyeao BT103 Sound Bar can be connected to various devices such as TVs, projectors, PCs, smartphones, tablets, DVD players, and gaming consoles using different connectivity options.

1. HDMI ARC: Connect the HDMI ARC cable from the sound bar to the HDMI ARC port on your TV.
2. Optical: Connect the optical cable from the sound bar to the optical port on your TV.
3. Coaxial: Connect the coaxial digital audio cable from the sound bar to the coaxial port on your TV.
4. AUX: Connect the AUX audio cable or AUX to RCA audio cable from the sound bar to the AUX port on your device.
5. Bluetooth: Pair your Bluetooth-enabled device with the sound bar by selecting "BT103" in the available devices list.
6. USB: Insert a USB flash drive with music files into the USB port on the sound bar.

4. Remote Control Functions

The remote control allows you to adjust various settings on your sound bar, such as power, volume, input source, sound mode, and more.

• Power: Turn the sound bar on or off.
• Volume +/-: Adjust the volume level.
• Mute: Mute or unmute the sound.
• Input: Switch between input sources (HDMI, Optical, Coaxial, AUX, Bluetooth, USB).
• 3D: Activate or deactivate the 3D surround sound mode.
• Bass +/-: Adjust the bass level.
• Treble +/-: Adjust the treble level.
• EQ: Switch between 10 different EQ modes (e.g., Rock, Pop, Jazz).

5. Adjusting Sound Settings

Customize the sound to your liking by adjusting the bass, treble, and EQ settings using the remote control.

1. Press the "Bass +/-" buttons to increase or decrease the bass level.
2. Press the "Treble +/-" buttons to increase or decrease the treble level.
3. Press the "EQ" button to cycle through the 10 different EQ modes.

6. Troubleshooting Tips

1. Ensure that the sound bar is properly connected to your device using the appropriate cables.
2. Check the input source on your sound bar and make sure it matches the connected device.
3. Set your TV's audio digital format to PCM and turn off Dolby sound.
4. When using HDMI ARC, ensure your TV is set to PCM output mode.
5. Disable Dolby and DTS features in streaming apps like Netflix, Hulu, and Amazon Prime, or select stereo output for compatibility.

7. Frequently Asked Questions

1. Can I use the sound bar and tower speakers simultaneously?

   No, you can only use the sound bar or tower speakers at one time. Use the line cable to combine the tower speakers into a sound bar or separate them for individual use.

2. What type of batteries does the remote control require?

   The remote control requires two AAA batteries, which are not included in the package.

3. How do I connect my smartphone to the sound bar?

   Enable Bluetooth on your smartphone and select "BT103" from the list of available devices to pair with the sound bar.

4. Can I play music from a USB flash drive?

   Yes, the sound bar features a USB port that allows you to play music directly from a USB flash drive.

Q: What are the connectivity options for this soundbar?
A: The GEOYEAO BT103 soundbar can be connected to devices via RCA, Bluetooth 5.0, auxiliary input, USB (flash drive only), optical, coaxial, and HDMI ARC.

Q: Can this soundbar be used as a tower speaker or a soundbar?
A: Yes, the split design of the GEOYEAO BT103 allows it to be used as either a tower speaker on the left and right sides of the TV or as an integrated horizontal style soundbar.

Q: Is it possible to adjust the bass and treble settings on this soundbar?
A: Yes, the GEOYEAO BT103 comes with bass and treble adjustable settings through remote control. It also has a built-in DSP that allows you to switch between 10 different EQ modes.

Q: Does this soundbar have a Bluetooth function?
A: Yes, the GEOYEAO BT103 includes Bluetooth 5.0 connectivity that lets you play music from your phone, PC, or tablet.

Q: How do I connect my TV to this soundbar?
A: To connect your TV to the GEOYEAO BT103, you will need to use the cables included in the package. Make sure your TV's audio port is set to Audio Out output and select the same audio output on the soundbar. When connecting via HDMI ARC Out connection mode, most TVs will automatically switch to PCM sound output mode compatible with the soundbar.

Q: Can I use this soundbar with my Android phone?
A: Yes, the GEOYEAO BT103 is compatible with both Android and iOS phones. You can easily pair your phone with the speaker via Bluetooth.

Q: What are the dimensions of each bar individually?
A: The dimensions of each bar individually are 16x3.9x2.9 inches (LxWxH). When combined as a soundbar, the dimensions are 32x3.9x2.9 inches (LxWxH).

Q: What is the wattage of the entire unit?
A: The wattage of the entire GEOYEAO BT103 unit is 120W.

Q: Is it possible to control the soundbar's volume with my TV remote?
A: Yes, you can adjust the volume of the GEOYEAO BT103 with your TV remote.

Q: Can I add wireless rear speakers to this soundbar?
A: The GEOYEAO BT103 can be accessed via Bluetooth, but it is not clear if it can push sound to wireless rear speakers. It is suggested to use wired connections for external speakers.

Q: Is wifi required to use this soundbar?
A: No, wifi is not required to use the GEOYEAO BT103 soundbar. It supports multiple wired connection and wireless Bluetooth connection.
