2022 WiFi Range Extender Signal Booster User Manual

Package Contents

• WiFi Range Extender
• User Manual

Product Overview

The 2022 WiFi Range Extender Signal Booster is designed to improve the Wi-Fi signal coverage in your home. With dual wireless bands of 2.4 GHz and 5 GHz, it can deliver data transfer speeds up to 1200Mbps. The device features 4 high gain external antennas and supports up to 5000 square feet of coverage and 35 devices. It also offers 3 modes: repeater, access point, and router.

Setup

There are two ways to set up the WiFi Range Extender:

1. WPS Button Setup:
   1. Plug the extender into an electrical outlet near your router.
   2. Press the WPS button on your router.
   3. Press the WPS button on the extender within 2 minutes. The LED lights on the extender will indicate a successful connection.
   4. Move the extender to the desired location, preferably halfway between your router and the area with weak Wi-Fi signal.
2. Web-based Setup:
   1. Plug the extender into an electrical outlet near your router.
   2. Connect your device (smartphone, tablet, or computer) to the extender's Wi-Fi network.
   3. Open a web browser and enter "192.168.10.1" in the address bar.
   4. Follow the on-screen instructions to complete the setup process.
   5. Move the extender to the desired location, preferably halfway between your router and the area with weak Wi-Fi signal.

Using the Extender in Access Point (AP) Mode

To use the extender as an access point, follow these steps:

1. Connect the extender to your wired network using an Ethernet cable.
2. Switch the mode on the extender to "AP".
3. Configure the extender's settings (SSID, security, etc.) as desired.

Troubleshooting Tips

• If you are unable to see the LED lights on the extender, try viewing them from a different angle or at eye level.
• If you are having trouble connecting to the extender using a web browser, try using the WPS button setup method instead.
• If the extender is not providing the desired Wi-Fi coverage, try moving it to a different location or adjusting the antennas.
• If you are experiencing slow speeds or connection issues, ensure that the extender is placed halfway between your router and the area with weak Wi-Fi signal.

Frequently Asked Questions

What is the maximum range of the extender?

The extender can provide coverage for up to 5000 square feet.

How many devices can the extender support?

The extender can support up to 35 devices.

Is the extender compatible with my router?

The extender is compatible with most Wi-Fi routers and devices that support 802.11n wireless communication standard.

Can the extender be used as an access point?

Yes, the extender can be used as a repeater, access point, or router.

How do I set up the extender using a web browser?

Connect your device to the extender's Wi-Fi network, open a web browser, and enter "192.168.10.1" in the address bar. Follow the on-screen instructions to complete the setup process.

Q: What is the maximum range of the 2022 WiFi Range Extender Signal Booster?
A: The 2022 WiFi Range Extender Signal Booster can extend up to 5000 square feet.

Q: How many devices can be connected to the 2022 WiFi Range Extender Signal Booster?
A: The 2022 WiFi Range Extender Signal Booster can connect up to 35 devices.

Q: What is the data transfer rate of the 2022 WiFi Range Extender Signal Booster?
A: The 2022 WiFi Range Extender Signal Booster has a data transfer rate of 1200 Megabits Per Second.

Q: Can the 2022 WiFi Range Extender Signal Booster be used with any internet provider?
A: It should work with any internet provider, but it's best to contact Amazon for confirmation.

Q: Can two of these be piggybacked for additional extended range?
A: It's unclear from customer reviews if two of these can be piggybacked for additional extended range.

Q: How is the setup process for the 2022 WiFi Range Extender Signal Booster?
A: There are two easy ways to set up the 2022 WiFi Range Extender Signal Booster - by pressing the WPS button on your router and the range extender button, or through a 2-minute setup process on the website 192.168.10.1.

Q: What are the dimensions and weight of the 2022 WiFi Range Extender Signal Booster?
A: The package dimensions of the 2022 WiFi Range Extender Signal Booster are 16.7 x 6.2 x 5.6 inches and it weighs 13.2 ounces.

Q: Does the 2022 WiFi Range Extender Signal Booster get hot when in use?
A: According to customer reviews, the device does not get hot when in use.

Q: Can I connect wired devices to the 2022 WiFi Range Extender Signal Booster?
A: Yes, the 2022 WiFi Range Extender Signal Booster has a fast ethernet port that can connect any wired device such as a smart TV, multimedia player, game console or PC to your WiFi network.

Q: What are the external antennas used for in the 2022 WiFi Range Extender Signal Booster?
A: The 2022 WiFi Range Extender Signal Booster has 4 high gain external antennas that eliminate dead areas and provide the best value and connection for your Internet needs.
