SAMCOM 5 Watts High Power Two-Way Radio User Manual

Package Contents

• Two-Way Radio x2
• 1500mAh Battery x2
• Long Antenna (6.7 inches) x2
• K-Type Earpiece x2
• Dock Charger (US Standard) x2
• Belt Clip (Already Assembled)

Getting Started

1. Unpack your SAMCOM two-way radio and ensure that all the items listed in the package contents are present.
2. Attach the long antenna to the radio by screwing it onto the antenna connector located on top of the radio.
3. Install the 1500mAh battery by sliding it into the back of the radio until it clicks into place.
4. Connect the dock charger to a power outlet and place the radio into the dock, ensuring that the charging contacts on the radio align with the contacts on the dock. Charge the radio until the battery is fully charged (approximately 5 hours).
5. Turn on the radio by rotating the power/volume knob located on the top of the radio.
6. Select a channel by rotating the channel knob located on the top of the radio.
7. Adjust the volume as needed by rotating the power/volume knob.
8. Attach the belt clip to the back of the radio if desired.
9. Connect the K-Type earpiece to the accessory jack on the side of the radio if desired.

Basic Operation

1. Press and hold the PTT (Push-to-Talk) button on the side of the radio to transmit your voice. Release the button to listen for incoming transmissions.
2. Use the left side PTT button for "direct calls" to the same channel members.
3. Use the GROUP PTT button to talk to other people simultaneously, even if they are not on the same channel.
4. Activate the backlit LCD display by pressing any button (except the PTT button) on the radio.
5. Adjust the volume by rotating the power/volume knob.

Advanced Features

1. Add private CDCSS codes to channels to prevent interference from irrelevant signals.
2. Switch between high and low power modes to optimize battery life and communication range.
3. Program the radio to be compatible with other brands' radios using the provided software (PC only, not compatible with Mac).

Troubleshooting Tips

• If the radio does not turn on, ensure that the battery is properly installed and fully charged.
• If the radio does not transmit or receive, check the antenna connection and ensure that the selected channel is not in use by other parties.
• If the battery is not charging, ensure that the charging contacts on the radio and dock are clean and properly aligned.
• If the range is not as expected, try using the high power mode and ensure that there are no obstructions or interference sources in the area.

Frequently Asked Questions

What is the range of these radios?

The range of these radios can vary depending on factors such as terrain, obstructions, and weather conditions. However, they are designed to provide clear communication at distances of up to several miles in optimal conditions.

Can these radios be used with other brands' radios?

Yes, these radios can be programmed to be compatible with other brands' radios using the provided software (PC only, not compatible with Mac).

How long does the battery last?

The 1500mAh lithium rechargeable battery provides up to 12 hours of working time and 50 hours of standby time.

Are these radios waterproof?

These radios are water-resistant but not fully waterproof. They can withstand exposure to light rain or moisture, but should not be submerged in water.

Can I use these radios for hunting or outdoor activities?

Yes, these radios are suitable for a variety of outdoor activities, including hunting, hiking, and camping, as well as for professional use in areas such as construction, security, and event management.

Q: Do you make 12v car charger for it?
A: Currently, we only offer a single-unit charger with an AC wall adapter or a 6-way multi-charger for the SAMCOM FPCN30A radio. We do not offer a USB car charger at this time. The single charge input is DC 12V, Output: DC 8.4V. However, we will forward your requirement to our related department and see if we can sell a car charger for the radio in the future.

Q: Are these pre-programmed or do they need to be programmed?
A: According to the dealer Sancom/Samcom, they are preprogrammed with the Sancom/Samcom channels used in their wireless intercom systems. From other users and reviewers, I have learned that these are in the FRS channels (462 and 467 MHz). From the FCC, I have learned that these radios are Part 90 approved business radios. They cannot be used legally to transmit on the FRS channels as that requires specific FCC approval (and a fixed antenna). If you intend to use these radios for business purposes, you must have an appropriate business license for specific frequency(ies) that this radio can transmit. If you get caught using them illegally, it can result in hefty fines.

Q: Cuanto cuesta solo 1 radio?
A: We suggest buying at least two radios since one cannot communicate alone. The price for one radio is $79 USD.

Q: Are these ready out of the box with the scrambler voice feature for security or does that need to be downloaded?
A: These walkie-talkies have a built-in SCR function and do not need to be downloaded again. Only when the same scrambling is turned on can the machines communicate with each other. If the scrambling frequency is different, the camera can receive the signal but cannot hear what is being said.

Q: I just received these today. Can these transmit to other walkie-talkies?
A: These are programmable radios and can work with other brands' radios. Please download the programmable software from our website and rewrite the frequencies. Link: http://www.sanconsales.com/download.html. Contact us via email address: [email protected].

Q: What is the range nominal outside flat terrain?
A: The communication range quoted is calculated based on an unobstructed line of sight test under optimum conditions. Up to 5 miles in the open area, 1-2 miles in construction area. Actual range will vary depending on terrain and conditions, and is often less than the maximum possible. Your actual range will be limited by several factors including, but not limited to: terrain, weather conditions, electromagnetic interference, and obstructions.

Q: I don't see if these can be used for biking or hiking and why do you need a license? If they are used in a factory or like I can see.
A: These SAMCOM FPCN30A walkie-talkies are suitable for biking and hiking. Due to the FCC requirement, above 2 Watts radio require an FCC license.

Q: What is the difference between SAMCOM FPCN30A and FPCN30AA?
A: There is no difference between SAMCOM FPCN30A and FPCN30AA. FPCN30A is the model number, while 2AIOQ-FPCN30AA is the FCC ID.

Q: Can I program with a Mac?
A: Unfortunately, we do not have software for programming with a Mac at this time.

Q: Your link for replacement battery for the FPCN 3A does not work. Can’t find it.
A: We apologize for any inconvenience. We have sent these batteries to Amazon warehouse, but they did not schedule to put them on sale. We will contact them and require them to update on Amazon as soon as possible. If you require a replacement battery, please contact us, and we would be happy to send free units to you. Email address: [email protected].
